Thickness Planer (old)

This tool requires safety training.
The steward for this tool is: Simon Clark
Certified trainers for this tool are: Brennan McKillop, Ken Brown, Mark Zander

20IN. PLANER WITH HELICAL CUTTERHEAD CSA CX20HC

Manual

Safety Precautions

Rotating Blade (potential loss of fingers and skin)
Flying debris (potential eye and face damage)
Entanglement of hair, jewelry or clothing

Protective Equipment (above minimum)

Safety Glasses
Hearing protection
Do not wear gloves, Tie back long hair. Avoid loose fitting clothing
Remove rings, watches, bracelets and other such jewelry

Issues

This tool produces lots of wood chips. You have to have the dust collector attatched or the chips will jam the machine causing over heating and potential for fire.

Unplug the tool before clearing any stuck chips

History and Ownership

20IN. PLANER WITH HELICAL CUTTERHEAD

MOdel : CX20SC

Motor : 220Volt, 60HZ, 1PH

Serial No. : SJ047



Maintanence Procedures

Here are some details which may help with regular maintanence of this tool.

These following details should not replace the recommended procedures contained in the tool manual.

Planer knife setting

Member Comments

You must log in to register a comment
- Dec 31 1969
Power died mid plane. Unplugged, plugged back in, does not restart
- Ryan Trinder Apr 09 2016
Power died mid plane. Unplugged, plugged back in, does not restart
- Ryan Trinder Apr 09 2016
Nice work, with lots of good ideas. I have been making rosettes on the lathe for years since the http://drillpressselect.com drill press likes to chatter and chew just before I hit the proper depth.
- drill press Jul 29 2015
New blades put in. We don't have a blade depth guide for this machine so you have to adjust the height manually. I set a dial gauge on the cutter shaft to zero. Then rotated over the blade and adjusted blade edge so it was aprox. 0.050" above the shaft. Ensure that blade is parallel to shaft and measure both sides. Then check manual for roller guide depth check.
